AMEISON 2400-2500MHz Outdoor Indoor WLAN Flat panel directional WIFI Antenna

AMEISON 2400-2500MHz Outdoor Indoor WLAN Flat panel directional WIFI Antenna

AMEISON 2400-2500MHz Outdoor Indoor WLAN Flat panel directional WIFI Antenna

Product Details:

Place of Origin: China
Brand Name: AMEISON
Certification: ISO 9001: 2008
Model Number: AMXW-2400-14G

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: EXW Price
Packaging Details: PP bag /inner box/master carton or customized
Delivery Time: 10-20 working days
Payment Terms: TT,Paypal,Western Union
Supply Ability: 50,000 Pieces per Month
Contact Now
Detailed Product Description
Frequency Range(MHz): 2400-2500 Bandwidth(MHz): 83
Gain(dBi): 14 VSWR: ≤1.5
Polarization: Vertical Lightning Protection: DC Ground
Input Connector Type: SMA Male Or Requested Mounting Way: Pole-holding
High Light:

wifi antenna

,

wi-fi antenna

,

antenna wifi outdoor

AMEISON 2400-2500MHz Outdoor Indoor WLAN Flat panel directional WIFI Antenna



Feature:

High gain,strong anti-interference ability

Good defense system

Full day working

Exquisite appearance

Optimized dimension

Application:

2.4GHZ WLAN system

2.4GHZ ISM band

WIFI communication system



AMXW-2400-14G

Electrical Specifications

Frequency range(MHz) 2400-2483
Bandwidth(MHz) 83
Gain(dBi) 14
Half-power beam width(°) H:30 V:30
VSWR ≤1.5
Input Impedance(Ω) 50
Polarization Vertical
Maximum input power(W) 50
Lightning protection DC Ground
Cable length (cm) 30
Input connector type SMA male or Requested
Mechanical Specifications
Dimensions-mm (Height/Width/Depth) 220*173*25
Antenna weight(kg) 0.58
Operating temperature(°c) -40~60
Rated Wind Velocity(m/s) 60
Radome color white
Mounting way pole-holding
Mounting hardware(mm) ¢35~¢50
