AMEISON 5725-5850MHz 17dBi Directional Outdoor Sector Panel Antenna Vertical and Horizontal polarization

AMEISON 5725-5850MHz 17dBi Directional Outdoor Sector Panel Antenna Vertical and Horizontal polarization

large.img.alt

Product Details:

Place of Origin: China
Brand Name: AMEISON
Certification: ISO 9001: 2008
Model Number: AMXP-5800VH-D17L90

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: EXW Price
Packaging Details: PP bag /inner box/master carton or customized
Delivery Time: 10-20 working days
Payment Terms: TT,Paypal,Western Union
Supply Ability: 50,000 Pieces per Month
Contact Now
Detailed Product Description
Frequency Range(MHz): 5725~5850 Polarization: Vertical And Horizontal
Gain(dBi): 17 VSWR: ≤1.5
Lightning Protection: DC Ground Input Connector Type: 2-N Female

AMEISON 5725-5850MHz 17dBi Directional Outdoor Sector Panel Antenna Vertical and Horizontal Polarization





Feature:

High gain

Full day working

Optimized dimension

Dual polarization



Application:

5.8 GHz WLAN system

5.8 GHz ISM band

Public wireless hot spot coverage



AMXP-5800VH-D17L90

Electrical Specifications

Frequency range(MHz) 5725~5850
Polarization Vertical and Horizontal
Gain(dBi) 2×17
Half-power beam width(°) H:90 V:7
Front-to-back ratio(dB) ≥23
Input Impedance(Ω) 50
VSWR ≤1.5
Isolation between ports ≥28dB
Cross-polar ratio ≥15dB@0º ≥10dB@+/-60º
Sidelobe suppression for first sidelobe above horizon 15 dB
Maximum input power(W) 200
Lightning protection DC Ground
Mechanical Specifications
Input connector type 2-N Female
Dimensions-mm (Height/Width/Depth) 580*114*54
Packing size(mm) 620*155*145
Antenna weight (kg) 3.0
Radome material UPVC
Radome color Gray
Mechanical tilt(°) 0~10
Operating temperature(°c) -40~60
Rated Wind Velocity(m/s) 60
Mounting hardware(mm) ¢35~¢90
