AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna

AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna

    • AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna
    • AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna
    • AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna
    • AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna
  • AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna

    Product Details:

    Place of Origin: China
    Brand Name: AMEISON
    Certification: ISO 9001: 2008
    Model Number: AMXW-2400-9

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: EXW Price
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
    Delivery Time: 10-20 working days
    Payment Terms: TT,Paypal,Western Union
    Supply Ability: 50,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 2400-2500 Bandwidth(MHz): 100
    Gain(dBi): 9 VSWR: ≤1.5
    Polarization: Circular(RHCP) Lightning Protection: DC Ground
    Input Connector Type: SMA Male Or Requested Mounting Way: Wall-hanging Or Pole-holding

    AMEISON 2400 - 2500 MHz Circular Polarized Wall Mount or pole mount Flat Patch Panel Antenna 9dbi 2.4ghz wifi Antenna



    Feature:

    High gain, strong anti-interference ability

    Good defense system

    Full day working

    Exquisite appearance

    Optimized dimension

    Application:

    2.4 GHZ WLAN system

    2.4 GHZ ISM frequency band

    Wi-Fi system



    AMXW-2400-9

    Electrical Specifications

    Frequency range(MHz) 2400-2500
    Bandwidth(MHz) 100
    Gain(dBi) 9
    Half-power beam width(°) H:50 V:50
    VSWR ≤1.5
    Input Impedance(Ω) 50
    Polarization Circular(RHCP)
    Maximum input power(W) 50
    Lightning protection DC Ground
    Input connector type SMA Female or N-Female or others
    Mechanical Specifications
    Dimensions-mm (Height/Width/Depth) 140*120*25
    Antenna weight(kg) 0.3
    Operating temperature(°c) -40~60
    Rated Wind Velocity(m/s) 60
    Radome material ABS
    Radome color white
    Waterproof Standard IP54/ IP65/ IP67
    Mounting way wall-hanging or pole-holding
    Mounting hardware(mm) ¢35 ~ ¢50
