| Place of Origin: | China |
| Brand Name: | AMEISON |
| Certification: | ISO 9001: 2008 |
| Model Number: | AMXW-2400-14B |
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | EXW Price |
| Packaging Details: | PP bag /inner box/master carton or customized |
| Delivery Time: | 10-20 working days |
| Payment Terms: | TT,Paypal,Western Union |
| Supply Ability: | 50,000 Pieces per Month |
| Frequency Range（MHz）: | 2400-2483 | Bandwidth（MHz）: | 83 |
|---|---|---|---|
| Gain（dBi）: | 14 | Half-power Beam Width（°）: | H：30 V：30 |
| VSWR: | ≤1.5 | Polarization: | Vertical |
| Lightning Protection: | DC Ground | Input Connector Type: | N Famle Or Requested |
| Mounting Way: | Wall-hanging Or Pole-holding | Mounting Hardware（mm）: | ￠35-￠50 |
| Highlight: | 2.4 antenna,wifi antenna 2.4ghz,antenna 2.4ghz |
||
2400-2483MHz Directional Wall Mount Antenna wireless wlan antenna
AMXW-2400-14B
Feature:
High gain,strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
2.4GHZ WLAN system
2.4GHZ ISM frequency band
WIFI frequency band communication system
|
AMXW-2400-14B Electrical Specifications |
|
|
Frequency range(MHz) |
2400-2483 |
|
Bandwidth(MHz) |
83 |
|
Gain(dBi) |
14 |
|
half-power beam width(°) |
H:30 V:30 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Maximum input power(W) |
100 |
|
Lightning protection |
DC Ground |
|
Input connector type |
N famle or Requested |
|
Mechanical Specifications |
|
|
Input connector type |
225*195*47 |
|
Antenna weight(kg) |
0.45 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Radome material |
ABS |
|
Radome color |
white |
|
Mounting way |
wall-hanging or pole-holding |
|
Mounting hardware(mm) |
￠35-￠50 |
