| Place of Origin: | China |
| Brand Name: | AMEISON |
| Certification: | ISO 9001: 2008 |
| Model Number: | AMXP-5158VH-D17L90 |
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | EXW Price |
| Packaging Details: | PP bag /inner box/master carton or customized |
| Delivery Time: | 10-20 working days |
| Payment Terms: | TT,Paypal,Western Union |
| Supply Ability: | 50,000 Pieces per Month |
| Frequency Range（MHz）: | 5100～5850 | Polarization: | Vertical And Horizontal |
|---|---|---|---|
| Gain（dBi）: | 2×16.5 | VSWR: | ≤1.7 |
| Maximum Input Power（W）: | 200 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2-N Female | Mounting Hardware（mm）: | ￠35～￠75 |
| High Light: | wireless antenna,wireless antenna outdoor,antenna wireless |
||
5100-5850MHz Directional Panel Antenna
AMXP-5158VH-D17L90
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
5.1 GHz～5.8 GHz WLAN system
5.1 GHz～5.8 GHz ISM frequency band
Public wireless hot spot coverage
|
AMXP-5158VH-D17L90 Electrical Specifications |
|
|
Frequency range(MHz) |
5100～5850 |
|
Polarization |
Vertical and Horizontal |
|
Gain(dBi) |
2×16.5 |
|
Half-power beam width(°) |
H:90 V:7 |
|
Front-to-back ratio(dB) |
≥23 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.7 |
|
Isolation between ports |
≥28dB |
|
Cross-polar ratio |
≥15dB@0º ≥10dB@+/-60º |
|
Sidelobe suppression for first sidelobe above horizon |
15 dB |
|
Maximum input power(W) |
200 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
2-N Female |
|
Dimensions-mm (Height/Width/Depth) |
580*114*54 |
|
Packing size(mm) |
620*155*145 |
|
Antenna weight (kg) |
3.0 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠35～￠75 |
