AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna

AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna

    • AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna
    • AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna
    • AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna
  • AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna

    Product Details:

    Place of Origin: China
    Brand Name: AMEISON
    Certification: ISO 9001: 2008
    Model Number: AMXW-8027-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: EXW Price
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
    Delivery Time: 10-20 working days
    Payment Terms: TT,Paypal,Western Union
    Supply Ability: 50,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 806~960/1710~2700 Bandwidth(MHz): 154/890
    Gain(dBi): 7/10 VSWR: ≤1.8
    Polarization: Vertical Lightning Protection: DC Ground
    Input Connector Type: N Female Or Requested

    AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna



    AMXW-7027-10

    Feature:

    High gain,strong anti-interference ability

    Good defense system

    Full day working

    Exquisite appearance

    Optimized dimension

    Application:

    Indoor coverage system

    CDMA800/GSM900/3G/WLAN system

    AMEISON Antenna Manufacturer 806-960/1710-2700MHz 7/10dBi Wide Band outdoor 4g LTE patch panel sector antenna

    AMXW-8027-10

    Electrical Specifications

    Frequency range(MHz)

    806~960/1710~2700

    Bandwidth(MHz)

    154/890

    Gain(dBi)

    7/10

    Half-power beam width(°)

    H:70/60 V:55/45

    VSWR

    ≤1.8

    Input Impedance(Ω)

    50

    Polarization

    Vertical

    Maximum input power(W)

    50

    Lightning protection

    DC Ground

    Input connector type

    N Female or Requested

    Mechanical Specifications

    Dimensions-mm (Height/Width/Depth)

    210*180*45

    Antenna weight(kg)

    0.57

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Radome material

    ABS

    Radome color

    white

    Mounting hardware(mm)

    ¢35-¢50
