Place of Origin: | China |
Brand Name: | AMEISON |
Certification: | ISO 9001: 2008 |
Model Number: | AMXF-1727-8 |
Minimum Order Quantity: | 20 |
---|---|
Price: | EXW Price |
Packaging Details: | PP bag or EPE/inner box/master carton or others |
Delivery Time: | 10-20 working days |
Payment Terms: | TT,Paypal,Western Union |
Supply Ability: | 50,000 Pieces per Month |
Frequency Range(MHz): | 1700-2700 | Bandwidth(MHz): | 1000 |
---|---|---|---|
Gain(dBi): | 8 | VSWR: | ≤1.5 |
Polarization: | Vertical | Lightning Protection: | DC Ground |
Input Connector Type: | N Female | Mounting Way: | Pole-holding |
1700 - 2700 MHz High gain 8dbi Outdoor 4G LTE Omnidirectional Antenna
Feature:
Exquisite appearance
Good impact resistance,
waterproofing and anticorrosion ability
Full day working
Optimized dimension
Low standing wave,
Strong anti-interference ability
Application:
CDMA/GSM/PCS/3G/4G/LTE/WLAN/WIFI system
Point-to-multipoint system
AMXF-1727-8 Electrical Specifications |
|
Frequency range(MHz) | 1710-2700 |
Bandwidth(MHz) | 990 |
Gain(dBi) | 68 |
Half-power beam width(°) | H:360 V:25 |
VSWR | ≤1.5 |
Input Impedance(Ω) | 50 |
Polarization | Vertical |
Maximum input power(W) | 100 |
Lightning protection | DC Ground |
Cable length | 30cm |
Input connector type | N female or Requested |
Mechanical Specifications | |
Dimensions (mm) | Φ60*750 |
Antenna weight(kg) | 1.5 |
Operating temperature(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Radome color | White |
Mounting way | Pole-holding or wall mount |
Mounting hardware(mm) | ¢35-¢50 |
