2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna

2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna

    • 2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna
    • 2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna
    • 2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna
  • 2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna

    Product Details:

    Place of Origin: China
    Brand Name: AMEISON
    Certification: ISO 9001: 2008
    Model Number: AMXW-2327-10B

    Payment & Shipping Terms:

    Minimum Order Quantity: 200
    Price: EXW Price
    Packaging Details: PP bag /inner box/master carton or others
    Delivery Time: 10-20 working days
    Payment Terms: TT,Paypal,Western Union
    Supply Ability: 50,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 2300-2700 Bandwidth(MHz): 400
    Gain(dBi): 10 VSWR: ≤1.5
    Polarization: Vertical Maximum Input Power(W): 50
    Lightning Protection: DC Ground Input Connector Type: SMA Male Or Requested
    Mounting Way: Wall-hanging Or Pole-holding
    High Light:

    wifi antenna

    ,

    2.4ghz antenna

    ,

    2.4 antenna

    2.3- 2.7GHz Outdoor or Indoor 10dBi Vertical Polarization 4G LTE WIFI Flat Panel Antenna



    Feature:

    High gain,strong anti-interference ability

    Good defense system

    Full day working

    Exquisite appearance

    Optimized dimension



    Application:

    2300-2700MHZ 4G LTE WIFI WLAN system

    2.4GHZ ISM frequency band



    AMXW-2327-10B

    Electrical Specifications

    Frequency range(MHz) 2300-2700
    Bandwidth(MHz) 400
    Gain(dBi) 10
    Half-power beam width(°) H:50 V:50
    VSWR ≤1.5
    Input Impedance(Ω) 50
    Polarization Vertical
    Maximum input power(W) 50
    Lightning protection DC Ground
    Input connector type SMA male or Requested
    Mechanical Specifications
    Dimensions-mm (Height/Width/Depth) 140*120*40
    Antenna weight(kg) 0.29
    Operating temperature(°c) -40~60
    Rated Wind Velocity(m/s) 60
    Radome material ABS
    Radome color white
    Mounting way wall-hanging or pole-holding
    Mounting hardware(mm) ¢35~¢50
