800-2700MHz High gain 15~17dbi Directional elevator shaft Panel Antenna

800-2700MHz High gain 15~17dbi Directional elevator shaft Panel Antenna

800-2700MHz High gain 15~17dbi Directional elevator shaft Panel Antenna

Product Details:

Place of Origin: China
Brand Name: AMEISON
Certification: ISO 9001: 2008
Model Number: AMXP-8027V-D1517L30

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: EXW Price
Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
Delivery Time: 10-20 working days
Payment Terms: TT,Paypal,Western Union
Supply Ability: 50,000 Pieces per Month
Contact Now
Detailed Product Description
Name: Elevator Shaft Antenna Connector: N-Female
Gain: 15~17 Polarization: Vertical
Frequency Range: 806-960/1710-2500-MHz Color: White
VSWR: 1.5 Beam Width: H:30 V:30 / H:20 V:20
Dimensions-mm: 606*606*110 Weight (kg): 12

800-2700MHz High gain 15~17dbi Directional elevator shaft Panel Antenna





Feature:

High gain
Full day working
Optimized dimension
Vertical or horizontal



Application:

CDMA/GSM/PCS/3G/WLAN/LTE system
Wireless communication and data transmission system





AMXP-8027V-D1517L30

Electrical Specifications

Frequency range(MHz) 806~960 1710~2700
Polarization Vertical
Gain(dBi) 15 17.5
Half-power beam width(°) H:30 V:30 H:20 V:20
Front-to-back ratio(dB) ≥25
Input Impedance(Ω) 50
VSWR ≤1.5
Maximum input power(W) 400 200
Lightning protection DC Ground
Mechanical Specifications
Input connector type N Female
Dimensions-mm (Height/Width/Depth) 606*606*110
Packing size(mm) 660*610*115
Antenna weight (kg) 12
Radome material UPVC
Radome color White
Mechanical tilt(°) 0~10
Operating temperature(°c) -40~60
Rated Wind Velocity(m/s) 60
Mounting hardware(mm)

Hanging
