3.5GHz 15dBi 65 Degrees Dual Polarized Wimax Antenna Directional Panel Antenna 120 Degree

3.5GHz 15dBi 65 Degrees Dual Polarized Wimax Antenna Directional Panel Antenna 120 Degree

3.5GHz 15dBi 65 Degrees Dual Polarized Wimax Antenna Directional Panel Antenna 120 Degree

Product Details:

Place of Origin: China
Brand Name: AMEISON
Certification: ISO 9001: 2008
Model Number: AMXP-3500S-D15L120

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: EXW Price
Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
Delivery Time: 10-20 working days
Payment Terms: TT,Paypal,Western Union
Supply Ability: 50,000 Pieces per Month
Contact Now
Detailed Product Description
Frequency Range(MHz): 3400-3600 Gain(dBi): 2*15
Polarization: ±45º Lightning Protection: DC Ground
VSWR: ≤1.5 Input Connector Type: 2-N Female

3.5GHz 15dBi 65 Degrees Dual Polarized Wimax Antenna Directional Panel Antenna 120 Degree



Feature:

High gain

Full day working

Optimized dimension

Dual polarization

Application:

3.5 GHz wireless access coverage



AMXP-3500S-D15L120

Electrical Specifications

Frequency range(MHz) 3400~3600
Polarization ±45º
Gain(dBi) 2×15
half-power beam width(°) H:120 V:7
Front-to-back ratio(dB) ≥25
Input Impedance(Ω) 50
VSWR ≤1.5
Isolation between ports ≥28dB
Cross-polar ratio ≥15dB@0º ≥10dB@+/-60º
Sidelobe suppression for first sidelobe above horizon 15 dB
Maximum input power(W) 200
Lightning protection DC Ground
Mechanical Specifications
Input connector type 2-N Female
Dimensions-mm (Height/Width/Depth) 760*114*54
Packing size(mm) 800*155*145
Antenna weight (kg) 3.6
Radome material UPVC
Radome color Gray
Mechanical tilt(°) 0~10
Operating temperature(°c) -40~60
Rated Wind Velocity(m/s) 60
Waterproof Standard IP67
Mounting way pole-holding
Mounting hardware(mm) ¢35~¢75
