800 - 2500 MHz 5dbi Vertical polarized 3G 4G LTE WIFI Omni directional Antenna

800 - 2500 MHz 5dbi Vertical polarized 3G 4G LTE WIFI Omni directional Antenna

    • small.img.alt
    • small.img.alt
    • small.img.alt
    • small.img.alt
  • large.img.alt

    Product Details:

    Place of Origin: China
    Brand Name: AMEISON
    Certification: ISO 9001: 2008
    Model Number: AMXF-8025-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: EXW Price
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
    Delivery Time: 10-20 working days
    Payment Terms: TT,Paypal,Western Union
    Supply Ability: 500,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 806-960/1710-2500 Gain(dBi): 5
    VSWR: ≤1.5 Polarization: Vertical
    Lightning Protection: DC Ground Input Connector Type: SMA Male Or Requested
    Name: 3G 4G LTE Omni Antenna

    800 - 2500 MHz 5dbi Vertical polarized 3G 4G LTE WIFI Omni directional Antenna





    Feature:

    Exquisite appearance

    Optimized dimension

    Full day working

    Wide frequency band,

    low standing wave,strong anti-interference ability



    Application:

    GSM/CDMA/PCS/3G/WLAN/WIFI/4G/LTE system

    Vehicle mobile communication device



    AMXF-8025-5

    Electrical Specifications

    Frequency range(MHz) 806-960 / 1710-2500
    Bandwidth(MHz) 154 / 790
    Gain(dBi) 3/5
    Half-power beam width(°) H:360 V:25
    VSWR ≤1.5
    Input Impedance(Ω) 50
    Polarization Vertical
    Maximum input power(W) 100
    Lightning protection DC Ground
    Cable length 30cm
    Input connector type N female or Requested
    Mechanical Specifications
    Dimensions (mm) Φ60*230
    Antenna weight(kg) 0.6
    Operating temperature(°c) -40~60
    Rated Wind Velocity(m/s) 60
    Radome color White
    Mounting way Pole-holding
    Mounting hardware(mm) ¢35-¢50
